Automatic Surgical Drape Folding Machine
Speed, Hygiene & Perfect Folding Performance in Medical Textile Production
Specially developed for the medical textile industry, this high-performance folding machine ensures flawless and automatic folding of surgical drapes with side tape and reinforcement fabrics. It's the ideal equipment for folding leg drapes, anesthesia drapes, plain drapes, and side-taped drapes used in surgical sets.
The fully automatic folding system enables consistent and standard folding without manual intervention. It offers 3 different final folding styles (longitudinal folds) to suit various packaging needs.
Why This Machine?
- Fully compatible with side-taped and reinforced drapes
- Maximum efficiency in folding different surgical drape types
- 3 automatic longitudinal fold options for packaging-ready results
- Repeatable, hygienic, and efficient process
- User-friendly interface and clean design
It’s a must-have solution for manufacturers aiming for consistency, speed, and quality in surgical drape production.
Technical Details
Machine description: Side tape cover machine, side tape and extra protection cover application is made to various fabrics. to the drapes used in angiography operations according to the desired features
Machine Includes Six Sections;
- UNWIDING
- SIDEBAND
- REINFORCEMENT
- FIRST FOLDING
- CUTTING
- FINAL FOLDING
Unwinder: It has automatic edge control, tension control and fabric loading systems. The system uses an air shaft for easy roll change.
Side Band: Side tape application on the fabric is done by applying double-sided adhesive tape or hotmelt. Tape length can be adjusted via HMI.
Reinforcement: The fabric to be used as reinforcement is first glued, then cut, and then glued to the main fabric with the help of vacuum conveyors.
First Folding: In the first folding section, while the fabric is in motion, folding is done along its width with folding bars in the desired dimensions.
Cutting: The fabric coming out of the first fold is cut to the desired length while moving. The drape length can also be adjusted via the HMI.
Final Folding: There are designs suitable for 3 different folding styles for the final folding section. These types are as follows; M fold, Z fold and longitudinal fold.
